1706A-E93TAG2 Diesel Engine
348 kVA @ 1500 RPM

The Perkins® 1700 Series is engineered to provide class
leading performance and maximise competitive advantage
for our customers.
Developed on a latest generation 9.3 litre core, the 1706
offers greater capability and more flexibility to our customers
from a simple plug and play product.

• Number of cylinders : 6 vertical in-line
• Bore and stroke : 115 x 149 mm 4.5 x 5.9 in
• Displacement : 9.29 litres 566.9 in3
• Aspiration : Turbocharged aftercooled
• Cycle : 4 stroke DI
• Combustion system : Direct injection
• Compression ratio : 16.5
• Rotation : Anti-clockwise, viewed on flywheel
• Total lubricating capacity : 26-30 litres
• Cooling system : Liquid
• Total coolant capacity : 33 litres

Dependable power

• World-class manufacturing capability and processes coupled with proven core engine designs assure reliability, quiet operation, and many hours of productive life
• A high power density product that combine dependable power and high efficiency at the same time. Driving lower cost of ownership along with better performance

Flexibility

• Tropical radiator is supplied as standard

Lifetime of low cost

• Fuel consumption optimized prime power and continuous running applications. No additional fluids or additives are required which lowers operating costs
• Vee belts and 500-hour oil change intervals enable low‑cost maintenance
• Perkins Platinum Protection – there is also an option to buy a Perkins Platinum Protection policy to cover you beyond the standard warranty period.

Local support, global coverage

• Perkins recognise that the customer relationship is important to machine manufacturers and we can offer a range of flexible solutions to help provide appropriate support, either to the OEM’s network or directly to the machine customer
• Perkins information systems enable our distributors to quickly diagnose engine faults and identify the right parts.The Perkins logistics operation is able to dispatch more than 45,000 different parts from stock, reaching the customer within 24 hours

Air inlet

• Standard air cleaners

Control system

• Full electronic control system
• All connectors and wiring looms waterproof and designed to withstand harsh environments
• Flexible and configurable software features and well supported SAE J1939 CAN bus enables highly integrated machines

Cooling system

• Tropical radiator as standard ensures optimal cooling performances all year round in any state
• 50:50 water glycol mix

Flywheels and flywheel housing

• SAE1 flywheel housing

Fuel and fuel system

• Electronic high pressure common rail
• Aluminium sump
